Reliable & affordable, smart & sustainable charging technologies for everyone, everywhere. VCHRGD believe in simple, effective and accessible charging technology for all. That means putting quality, reliability and safety above all else.
Features
- Hard wired dynamic load balancing with CT provided in box. Never overload your main supply
- Simple installation with modular charging hardware, increased wiring area push fit connection
- Longer, universal type 2 socket or tethered 7.5 metre type 2 cable
- Save money by charging at off-peak times. Combine solar and EV tariffs for supercharged savings
- Our chargers monitor your solar export allowing you to charge for free with 1 or 2 CT Inputs
- Turning untethered chargers into tethered at the touch of a button. Secure your cable
- Built-in RFID & WiFi as standard with optional 4G & Ethernet, connect anywhere
- Compliant with all UK smart charging standards & encrypted bluetooth, WiFi & RFID
Specification
- Electrical: Charger type - Mode 3 (IEC61851-1), Nominal supply - Single phase 230V, 50/60Hz, Charging power - Up to 32A (7kW), Over current protection - 40A, Current rating - Adjustable (6A to 32A), Standby power consumption - < 2.5W, Earth leakage protection - AC 30mA + DC 6mA, PEN protection - PE Current (BS7671:722.411.4.1 Ident ii & v), Supply connection - L, N + PE / CT1 + CT2
- Connectivity: WiFi - (IEEE 802.11bgn) @ 2.4Ghz WPA-2, Connection security - Transport Layer Secure Encryption HTTPS, Bluetooth - 2.4GHz, RFID - ~120 -140kHz, 4G Cellular *Optional* - ~ 600 MHz –2.5 GHz
- Dimensions: 319mm (H), 180mm (W), 105mm (D), Weight - 3kg
- Safety And Operational: Status indication - LED, Operating ambient temperature - -25°C to +50°C, Relative humidity - 5% to 90%, Atmospheric pressure - 80kPA –110kPA, EMC compliance - EN55011 Class B, IP/IK class - IP55/IK10
Get the Seven Pro installed by Earth Electrical
Why choose Earth Electrical for your VCHRGD product installations?
Our team of seasoned professionals is well-versed with the distinct nuances of VCHRGD's product range, ensuring an installation process that is smooth, efficient, and tailored to your specific requirements. Furthermore, our commitment to fostering a greener future aligns seamlessly with VCHRGD's sustainability ethos, making us the perfect partner to help you step into the solar EV and batteries with confidence and ease. Entrust us with your installation needs and join countless satisfied customers in making a conscious choice for the environment, without compromising on quality and convenience.
Get a free quote
